WEIR MINERALS (WARMAN) / (Floway pumps) is the world leader in the design and manufacture of pumps, mill liners, cyclones and slurry valves for the mining andminerals processing industries. Based on advanced, patented materials and design, our products and support services add value to virtually any aggressive, corrosive process
| Model | HA |
| Application | Mill discharge Process pumps, Low pressure tailings |
| Pressure(Max.) | 20.6 bar |
| Temp(Max) | 280 °C |
| Capacity(Max) | 18,000 m³/hr |
| Discharge size | 25 - 1,200 mm |
| Liner Material | Natural rubber, Synthetic rubber, Chrome, Alloy Etc. |
| Model | Q-Series |
| Application | Salt & potash, Pulp & paper Chemicals, Metals and mining |
| Pressure(Max.) | 69 bar |
| Temp(Max) | 200 °C |
| Capacity(Max) | 7,000 m³/hr |
| Discharge size | 700 - 2000 mm |
| Liner Material | Cast iron, Carbon steel Austenitic, Duplex or 6Mo ss., Nickel, Nickel-copper, Nickel-chrome, moly alloys, Titanium |
| Model | SHW |
| Application | Mine dewatering, Mill scaleClean up sumps, Lime slurry |
| Pressure(Max.) | 12 bar |
| Temp(Max) | 80 °C |
| Capacity(Max) | 2,275 m³/hr |
| Discharge size | 50 - 400 mm |
| Liner Material | Natural rubber, Synthetic rubber, Chrome, Alloy Etc. |
| Model | SP/SPR |
| Application | Slurry Sump pump |
| Pressure(Max.) | 7.4 bar |
| Temp(Max) | 100 °C |
| Capacity(Max) | 1,000 m³/hr |
| Discharge size | 40 - 300 mm |
| Liner Material | Natural rubber, Synthetic rubber, Chrome, Alloy Etc. |
| Model | TC |
| Application | Vortex design to pass larger particles |
| Pressure(Max.) | 6 bar |
| Temp(Max) | 100 °C |
| Capacity(Max) | 1600 m³/hr |
| Discharge size | 50 - 250 mm |
| Liner Material | Cast iron, Carbon steel Austenitic, Duplex or 6Mo ss., Nickel, Nickel-copper, Nickel-chrome, moly alloys, Titanium |
| Model | WBH |
| Application | Mill discharge,Process pumps Low pressure tailing |
| Pressure(Max.) | 20.6 bar |
| Temp(Max) | 100 °C |
| Capacity(Max) | 3,000 m³/hr |
| Discharge size | 25 - 300 mm |
| Liner Material | Natural rubber, Synthetic rubber, Chrome, Alloy Etc. |
| Model | WBV |
| Application | Slurry Sump pump |
| Pressure(Max.) | 7.4 bar |
| Temp(Max) | 100 °C |
| Capacity(Max) | 1,000 m³/hr |
| Discharge size | 40 - 150 mm |
| Liner Material | Natural rubber, Synthetic rubber, Chrome, Alloy Etc. |
| Model | XU |
| Application | General Purpose Slurry Pump |
| Pressure(Max.) | 10.3 bar |
| Temp(Max) | 100 °C |
| Capacity(Max) | 2,275 m³/hr |
| Discharge size | 75 - 300 mm |
| Liner Material | Cast iron, Carbon steel Austenitic, Duplex or 6Mo ss., Nickel, Nickel-copper, Nickel-chrome, moly alloys, Titanium |
